JVC TH-S77 User Manual

3-16
Mother board
Block No. [0][3]
R2563 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2564 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2565 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2566 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2567 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2568 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2581 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2582 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2583 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2584 NRSA63J-623X MG RESISTOR 62k Ω 1/16W J
R2585 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2586 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R2587 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2588 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2590 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2592 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2594 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2596 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2597 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2598 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2599 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6001 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6004 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7101 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7102 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7103 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7104 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7105 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R7106 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R7107 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R7201 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7202 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7401 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R7402 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R7403 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7404 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7601 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7602 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7603 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R7604 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7605 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7606 NRSA63J-433X MG RESISTOR 43k Ω 1/16W J
R7607 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R7901 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R7902 QRE141J-471Y C RESISTOR 470 Ω 1/4W J
R7903 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R7904 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
VR701 QVQ0320-B54 V RESISTOR
BK501 LV43659-001A FL HOLDER
BK502 LV43659-001A FL HOLDER
CN441 QGF1036C1-29 CONNECTOR FFC/FPC (1-29)
CN442 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
CN501 QGF1036F1-13 CONNECTOR FFC/FPC (1-13)
CN511 QGF1205F1-05 CONNECTOR FFC/FPC (1-5)
CN760 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
DI501 QLF0154-001 FL TUBE
FW443 QJP019-021600-E F.WIRE
FW512 QUM022-11Z4Z4-E F.WIRE
FW601 QUM154-17DGZ4-E F.WIRE
J1101 QNN0215-001 SURROUND JACK
J1103 QND0118-001 DIN CONNECTOR
J6001 QNS0231-001 JACK
J7001 QNS0231-001 JACK
J7002 QNS0231-001 JACK
K1101 NQR0007-002X FERRITE BEADS
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
K7001 NQR0007-002X FERRITE BEADS
S521 QSW0683-001Z PUSH SW
S522 QSW0683-001Z PUSH SW
S523 QSW0683-001Z PUSH SW
S524 QSW0683-001Z PUSH SW
S526 QSW0683-001Z PUSH SW
S527 QSW0683-001Z PUSH SW
S528 QSW0683-001Z PUSH SW
 Symbol No. Part No. Part Name Description Local
S529 QSW0683-001Z PUSH SW
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-430 IC
 IC202 STK413-400 IC
IC301 RC4558D-X IC
IC302 RC4558D-X IC
IC303 RC4558D-X IC
IC601 MN101C427NB IC
Q152 KTC2026/Y/ TRANSISTOR
Q501 KRA104S-X DIGI TRANSISTOR
Q502 KTC3875/YG/-X SI TRANSISTOR
Q503 KTC3875/YG/-X SI TRANSISTOR
Q504 KTA1504/YG/-X SI TRANSISTOR
Q505 KRC109S-X TRANSISTOR
Q517 KRC104S-X TRANSISTOR
Q523 KTC3875/YG/-X SI TRANSISTOR
Q524 KTA1504/YG/-X SI TRANSISTOR
Q525 KTC3875/YG/-X SI TRANSISTOR
Q542 KTC3875/YG/-X SI TRANSISTOR
Q603 KTC3875/YG/-X SI TRANSISTOR
Q604 KTC3265/Y/-X TRANSISTOR
Q2101 KTA1504/YG/-X SI TRANSISTOR
Q2201 KTA1504/YG/-X SI TRANSISTOR
Q2301 KTA1504/YG/-X SI TRANSISTOR
Q2401 KTA1504/YG/-X SI TRANSISTOR
Q2501 KTA1504/YG/-X SI TRANSISTOR
Q2601 KTA1504/YG/-X SI TRANSISTOR
Q2701 KTC3875/YG/-X SI TRANSISTOR
Q2702 KTA1046/Y/ TRANSISTOR
Q2703 KRC102S-X DIGI TRANSISTOR
Q2707 KTA1267/YG/-T TRANSISTOR
Q2708 KTC3199/GL/-T TRANSISTOR
Q2709 KTC2026/Y/ TRANSISTOR
Q2710 KTA1504/YG/-X SI TRANSISTOR
Q2711 KRA102S-X DIGI TRANSISTOR
Q3101 KTC3875/YG/-X SI TRANSISTOR
Q3102 KTC3875/YG/-X SI TRANSISTOR
Q3201 KTC3875/YG/-X SI TRANSISTOR
Q3202 KTC3875/YG/-X SI TRANSISTOR
Q3301 KTC3875/YG/-X SI TRANSISTOR
Q3302 KTC3875/YG/-X SI TRANSISTOR
Q3401 KTC3875/YG/-X SI TRANSISTOR
Q3402 KTC3875/YG/-X SI TRANSISTOR
Q3501 KTC3875/YG/-X SI TRANSISTOR
Q3502 KTC3875/YG/-X SI TRANSISTOR
Q3701 KRA102S-X DIGI TRANSISTOR
Q3702 KRA102S-X DIGI TRANSISTOR
Q3703 KRC103S-X DIGITAL TR
Q3704 KTC2026/Y/ TRANSISTOR
Q3705 KTC3875/YG/-X SI TRANSISTOR
Q3706 KRC104S-X TRANSISTOR
D101 1SS355-X SI DIODE
 D151 GBU803 BRIDGE DIODE
 D152 GBU803 BRIDGE DIODE
D154 1SS133-T2 SI DIODE
D163 1SS133-T2 SI DIODE
D164 MTZJ6.2A-T2 Z DIODE UP
D164 MTZJ6.2B-T2 Z DIODE
UG,UN,US,
UX,UT
D165 MTZJ6.8C-T2 Z DIODE
D166 MTZJ6.8C-T2 Z DIODE
D501 1SS133-T2 SI DIODE
D504 1SS133-T2 SI DIODE
D505 UDZS5.1B-X Z DIODE
D506 1SS133-T2 SI DIODE
D507 1SS355-X SI DIODE
D510 1SS133-T2 SI DIODE
 Symbol No. Part No. Part Name Description Local
