3-19
R2611 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R2612 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R2613 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R2614 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R2615 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J UP
R2701 QRZ9005-220X FUSI RESISTOR 22
Ω
R2702 QRZ9005-220X FUSI RESISTOR 22
Ω
R2703 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R2704 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R2705 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R2706 QRZ9006-4R7X F.RESISTOR 4.7
Ω
1/4W J
R2707 QRZ9006-4R7X F.RESISTOR 4.7
Ω
1/4W J
R2708 QRZ9006-4R7X F.RESISTOR 4.7
Ω
1/4W J
R2709 QRZ9006-4R7X F.RESISTOR 4.7
Ω
1/4W J
R2710 QRZ9005-100X FUSI RESISTOR 10
Ω
R2711 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R2712 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R2713 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R2721 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R2722 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R2723 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R2724 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R3101 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R3103 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3104 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3105 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R3106 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3107 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R3108 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3109 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3110 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3111 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3112 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3113 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3201 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R3203 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3204 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3205 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R3206 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3207 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R3208 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3209 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3210 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3211 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3212 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3213 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3301 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R3303 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3304 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3305 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R3306 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3307 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R3308 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3309 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3310 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3311 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3312 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3313 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3401 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R3403 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3404 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3405 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R3406 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3407 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R3408 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3409 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3410 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3411 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3412 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3413 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3501 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R3503 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3504 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3505 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R3506 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3507 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R3508 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3509 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R3510 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3511 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3512 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3513 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3601 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R3603 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3604 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R3605 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R3607 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3608 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3610 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R3611 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R3717 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3719 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R3720 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R3721 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R3725 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R3726 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3727 QRL01DJ-180X OMF RESISTOR 18
Ω
1W J
R3728 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3729 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R3730 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R3732 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R3741 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R3742 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
L2101 QQLZ005-R45 COIL 0.45uH
L2201 QQLZ005-R45 COIL 0.45uH
L2202 QQLZ005-R45 COIL 0.45uH UP
L2301 QQLZ005-R45 COIL 0.45uH
L2302 QQLZ005-R45 COIL 0.45uH UP
L2401 QQLZ005-R45 COIL 0.45uH
L2402 QQLZ005-R45 COIL 0.45uH UP
L2501 QQLZ005-R45 COIL 0.45uH
L2502 QQLZ005-R45 COIL 0.45uH UP
L2601 QQLZ005-R45 COIL 0.45uH
L2602 QQLZ005-R45 COIL 0.45uH UP
B1 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
B21 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
CN102 QGA7901C1-02 CONNECTOR W-B (1-2) UP
CN102 QGA7901C1-04 CONNECTOR W-B (1-4)
UG,UN,US,
UX,UT
CN151 QGA3901C1-05 CONNECTOR W-B (1-5)
CN271 QGB2510J1-14 CONNECTOR B-B (1-14)
CN272 QGB2510J1-09 CONNECTOR B-B (1-9)
CN273 QGB2510J1-14 CONNECTOR B-B (1-14)
CN274 QGA3901C1-02 CONNECTOR W-B (1-2)
CN371 QGA2501C1-02 CONNECTOR W-B (1-2)
CN372 QGB2510K2-09 CONNECTOR B-B (1-9)
CN501 QGB2510K2-14 CONNECTOR B-B (1-14)
CN502 QGB2510K2-14 CONNECTOR B-B (1-14)
EP201 QNZ0136-001Z EARTH PLATE
EP501 QNZ0136-001Z EARTH PLATE
FC101 QNG0019-001Z FUSE CLIP
FC102 QNG0019-001Z FUSE CLIP
FC103 QNG0019-001Z FUSE CLIP
UG,UN,US,
UX,UT
FC104 QNG0019-001Z FUSE CLIP
UG,UN,US,
UX,UT
FC155 QNG0019-001Z FUSE CLIP
FC156 QNG0019-001Z FUSE CLIP
FC157 QNG0019-001Z FUSE CLIP
FC158 QNG0019-001Z FUSE CLIP
FW501 QUM213-28Z4Z4-E RIBBON WIRE
HS151 QZW0138-001 HEAT SINK
J2701 QND0118-001 DIN CONNECTOR
J2702 QNB0195-001 SPEAKER TERMINA
RY101 QSK0142-001 RELAY
RY271 QSK0127-001 RELAY
RY272 QSK0127-001 RELAY
RY273 QSK0127-001 RELAY
S901 QSW0924-001 VOLTAGE SWITCH
UG,UN,US,
UX,UT
TH271 NAD0025-103X N THERMISTOR 10k
Ω
WC201 QZW0112-001 WIRE CLAMP
X601 QAX0246-001Z C RESONATOR 8.00MHz
Symbol No.
Part No. Part Name Description Local
