Installation Instructions Powador 2500xi / 3600xi / 4000xi / 4500xi / 5000xi_EN Page 23
8.3 Notes specifi c to the Powador 5000xi
Sample confi gurations:
L1: Powador 5000xi L2: Powador 5000xi L3: Powador 1501xi Asymmetry: 3.7 kW
L1: Powador 5000xi L2: Powador 5000xi L3: Powador 2500xi Asymmetry: 2.7 kW
L1: Powador 5000xi L2: Powador 5000xi L3: Powador 3600xi Asymmetry: 1.9 kW
L1: Powador 5000xi L2: Powador 4000xi L3: Powador 4000xi Asymmetry: 0.8 kW
L1: Powador 5000xi L2: Powador 4000xi L3: Powador 4500xi Asymmetry: 0.6 kW
Section 8 · Powador as Part of a PV Installation
NOTE
The Powador 5000xi is designed for installations with sev-
eral inverters, and, at 5.5 kW, is above the limit for single-
phase feed into the grid. It, therefore, may be operated
only together with at least two additional inverters in order
to ensure that the asymmetry is not greater than 4.6 kW (in
Germany). For this, the inverters are distributed over all
three phases (according to VDEW).
