9.800-103.0 - M • Karcher HDS 615-617
35
PRESSURE WASHER
OPERATOR’S MAN U AL
ENGINE ASSEMBLIES PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 9.802-154.0 Plug, Push-On Drain,
Honda (615.0) 1
9.802-039.0 Elbow, 1/2" JIC, 3/8",
90° (616.0, 617.0) 1
2 8.709-069.0 Clamp, Screw, #4 (615.0) 1
9.802-151.0 Swivel, 1/2" JIC Fem.,
Push-On (616.0, 617.0) 1
3 9.802-254.0 Hose, 1/4" Push-On,
Fuel Line (615.0) 18”
9.802-259.0 Hose, 1/2" Push-On
(616.0, 617.0) 16”
4 9.802-153.0 Swivel, 1/4" JIC Female,
Push-On (615.0) 1
9.802-151.0 Swivel, 1/2" JIC Fem.,
Push-On (616.0, 617.0) 1
5 9.802-125.0 Plug, 1/4" JIC (615.0) 1
9.802-126.0 Plug, 1/2" JIC, Flare,
639F-8 (616.0, 617.0) 1
6 9.802-764.0 Screw, 10/32” x 3/4”,
Hex Wash SL Machine
Black (616.0, 617.0) 1
7 9.802-203.0 Clamp, 1/2" RO-Clip,
Kleinhuis (616.0, 617.0) 1
8 9.802-695.0 Nut, 10/32" Keps
(616.0, 617.0) 1
9 8.750-579.0 Engine, Honda,
GX390UT2QNR2, (389 CC)
E/S, 18 Amp (615.0) 1
8.754-819.0 Engine, Vanguard (570 CC)
E/S, 20 Amp (616.0) 1
8.752-149.0 Engine, Honda,
GX630R, No Throttle
17 AMP (617.0) 1
10 9.803-631.0 Muffl er, Exhaust, Briggs
(616.0) 1
8.750-497.0 Muffl er, Honda,
GX630/GX670, (688 CC)
Right (617.0) 1
8.739-597.0 ▲ Bolt, Flange, M8 x 20
(617.0) 2
9.802-798.0 ▲ Screw, #10-1/2",
Tek, HH, SS (617.0) 1
11 8.750-737.0 Adapter, Honda
M20-1.5 x 3/8" FPT 1
12 6.390-126.0 Clamp, Hose,
.46-.54 ST (617.0) 5
13 8.709-152.0 Filter, Fuel Disposable
(617.0) 1
14 9.802-254.0 Hose, 1/4" Push-On,
Fuel Line (617.0) 2 ft.
ITEM PART NO. DESCRIPTION QTY
15 8.706-950.0 Hose Barb, 1/4" Barb x
1/8" ML Pipe, 90° (617.0) 2
16 9.802-753.0 Screw, 1/4" x 3/4"
HH NC, Whiz Loc (617.0) 2
17 8.933-005.0 Pump, 12V Fuel, Facet
(617.0) 1
18 9.802-775.0 Nut, 1/4" Flange, Zinc
(617.0) 2
19 9.802-204.0 Clamp, Hose 1
20 9.802-830.0 Screw, 1/4"-20 x 1/2",
T/F CS ZN 4
21 9.802-867.0 Guard, Muffl er, Vanguard 1
22 9.802-868.0 Brace, Vanguard
Muffl er Bracket 2
23 9.802-794.0 Nut, Cage,
1/4” x 12 Gauge 2
24 9.802-754.0 Screw, 1/4" x 1/2" HH
NC, Whiz Loc
9.802-830.0 Screw, 1/4"-20 x 1/2",
T/F CS ZN 4
25 8.753-066.0 Clamp, 1 Ear
12.6-14.5mm #7 3
26 8.753-269.0 Reducer, Connector
1/4" x 3/16" 1
27 9.802-254.0 Hose, Push-On 36"
28 8.753-065.0 Clamp, 1 Ear
15.7-18.5mm #10 1
29 8.711-785.0 Hose, 3/8" Push-On 4"
30 8.753-270.0 Reducer, Connector
3/8" x 1/4" 1
31 9.802-254.0 Hose, 1/4' Push-On 32"
32 8.718-781.0 Screw, Pan Head 1
▲ Not Shown
