KT.2 SERIES PUMP EXPLODED VIEW PARTS LIST
KIT NUMBERS 8.753-821.0 8.753-822.0 8.753-823.0 8.753-824.0 8.752-835.0
KIT DESCRIPTION
Plunger Seals
18 mm
Seal Packing
18 mm
Plunger
18 mm Complete Valve
Plunger Oil
Seals
ITEMS NUMBERS
INCLUDED
3, 5, 7 3, 4, 5, 6, 7, 34, 35, 36, 37 11, 12, 13 2
NO. OF CYLINDERS
KIT WILL SERVICE
31163
ITEM PART NO. DESCRIPTION QTY
33 9.803-181.0 Bearing Housing 1
34* 8.752-841.0 Plunger Bolt 3
35* 8.752-820.0 Bonded Seal 3
36* 8.753-819.0 Plunger, 18mm
3
37* 8.752-823.0 Copper Spacer 3
38 8.753-820.0 Plunger Rod 3
39 8.752-822.0 Connecting Rod Pin 3
40 8.752-821.0 Connecting Rod 3
41 9.802-889.0 Spring Washer 6
42 9.802-937.0 Connecting Rod Screw 6
43 9.803-194.0 O-Ring Ø2.62 x 152.07 1
44 8.752-826.0 Crankcase Cover 1
45 9.803-906.0 O-Ring Ø1.78 x 14.00 1
46 8.707-262.0 Brass Plug G3/8 1
47 9.803-202.0 Sight Glass G3/4 1
48 8.752-824.0 Cover Screw 5
