Kärcher HD 10/25-4 Cage Plus User Manual

English 19
Technical specifications
Main Supply
Voltage V 400/420
Current type Hz 3~ 50
Connected load kW 9,2
Protection (slow, char. C)) A 16
Maximum allowed net impedance Ohm (0.167
+j0.104)
Extension cable 10 m mm
2
2,5
Extension cord 30 m mm
2
4
Water connection
Max. feed temperature °C 60
Min. feed volume l/h (l/min) 1200 (20)
Suck height from open container (20 °C) m 0,5
Max. feed pressure MPa (bar) 1 (10)
Performance data
Working pressure MPa (bar) 25 (250)
Max. operating over-pressure MPa (bar) 27,3 (273)
Flow rate l/h (l/min) 1000 (16,7)
Detergent suck in l/h (l/min) 0...80 (0...1,3)
Max. recoil force of hand spray gun N 62
Noise emission
Sound pressure level (EN 60704-1) dB(A) 76
Guaranteed sound power level (2000/14/EC) dB(A) 92
Machine vibrations Vibration total value (ISO
5349)
Hand spraygun m/s
2
3,6
Spray lance m/s
2
4,2
Fuel
Amount of oil l 1,2
Oil grade SAE 90
Dimensions and weights
Length mm 608
Width mm 546
Height mm 1174
Weight (without accessories) kg 62

Kärcher HD 10/25-4 Cage Plus Specifications

General

Connected load	9200 W
AC input voltage	400 V
Number of phases	3
AC input frequency	50 Hz
Maximum pressure	273 bar
Working pressure (max)	250 bar

Weight and Dimensions

Depth	543 mm
Width	547 mm
Height	1104 mm
Weight	62000 g
