Operating instructions KM 100/100 R D English
37
Machine making dust
! Empty debris container
! Check drive belts for the suction
turbine
! Check sealing cup at the suction
turbine
! Check dust filter, dedust or
replace it
! Check filter box seal
! Check sealing strips for wear,
adjust or replace them as
required
Poor sweeping around the edges
! Replacing the side broom
! Check sealing strips for wear,
adjust or replace them as
required
! Notify the Kärcher service station
Activation of side brush or main
brush does not function
! Check the seal on the vacuum
system
! Check (sweeping) hydraulic
system for leaks
! Notify the Kärcher service station
The lowering mechanism of the
side brushes or the main brush
does not function
! Check the seal on the vacuum
system
! Notify the Kärcher service station
Accessories
Side brush 6.905-986
Provided with standard bristles for
indoor and outdoor surfaces.
Soft side broom 6.906-133
For fine dust on indoor surfaces,
resistant to moisture.
Hard side broom 6.906-065
For cleaning hard to remove dirt
from outdoor surfaces.
Standard main brush 6.906-375
Wearproof and wetproof.
Universal bristles for indoor and
outdoor cleaning.
Main brush soft 6.906-533
With natural bristles specially for
sweeping fine dust on smooth
indoor floors. Not moisture-resistant,
not for abrasive surfaces.
Main brush hard 6.906-532
For removing stubborn external dirt,
damp-proof.
Dust filter 6.414-532
Technical data
Unit data
Length x width x height
2006 x 1005 x 1343 mm
Empty weight 315 kg
Permissible total weight 535 kg
Driving speed
8 km/h
Sweeping speed 6 km/h
Climbing ability max. 18 %
Main brush diameter 285 mm
Main brush width 710 mm
Side brush diameter 450 mm
Area performance
without side brush 7300 m²/h
with side brush 10400 m²/h
Working width
without side brush 710 mm
with side brush 1000 mm
Volume of debris
container 100 litres
Protection class drip-proof
IPX 3
Engine
Type Yanmar L70AE-DE,
1-cylinder four stroke
Displacement 296 cm³
Power, max. 4,4 kW/6 PS
at 3600 1/min
Fuel, diesel 3,3 l
Type of protection IP 22
Battery 12 V, 44 Ah
Fuel consumption ca. 1,5 l/h
Oil types
Engine approx. 1,1 l
SAE 15 W 40
Sweeper hydraulics HVLP 46
Axle drive SAE 10 W 60
Tyres
Large-size, front 4.00-4
Air pressure - front 6 bar
Large-size, rear 4.00-8
Air pressure - rear 6 bar
Brake
Service brake hydrostatic
Parking brake automatic
(with spring)
Filter and suction system
Fine dust filter surface 6,0 m²
Filter’s application class U
for non-health hazardous dusts
Rated vacuum of
suction system 12 mbar
Rated volumetric flow of
suction system 50 l/s
Ambient conditions
Temperature -5 - +40° C
Atmospheric humidity,
non-dew developing 0 - 90 %
Machine vibration
Total vibration value (ISO 5349)
Right arm 1,8 m/s²
Left arm 1,8 m/s²
Feet/seat area 0,7 m/s²
Noise emission
Sound pressure level
(EN 60704-1) 83 dB(A)
Garanteed sound
power level
(2000/14/EC) 101 dB(A)
