English 21
Î Tightly insert the steam plug (C7) into the
appliance connector (A1). The locks of
the steam plug must lock into the cover of
the appliance connector (see Figure 5).
Figure 5
Î Connect the required accessories (D1,
E1, F1) with the steam gun (C1). Insert
the open end of the accessory on the
steam gun (C1) and push onto the steam
gun until the unlocking button (C2) of the
steam gun locks into place (see Fig. 6).
Figure 6
Î Use the extension pieces (G1) if neces-
sary. To do so, connect one or both ex-
tension pieces to the steam gun (C1)
(see Fig. 7). Insert the required accesso-
ries (D1, E1, F1, H1) on the free end of
the extension piece.
Figure 7
Î The detail nozzle (D1) may also be used
with the extension piece (D2), the round
brush (D3), or the power nozzle (D4)
(see Fig. 8). To do so, put the two
grooves of the attachments on the locks
of the detail nozzle and turn clockwise
until the stop.
Figure 8
몇 DANGER
Hot water may drip out of the accessory
parts while you are detaching them! Never
detach accessory parts while steam streams
out - risk of scalds!
Î To detach the accessory parts, press the
unlocking button (C2 or G2), and pull the
items apart (see Figure 9).
Figure 9
Î To detach an attachment from the detail
nozzle, turn the attachment counter-
clockwise and pull the parts apart.
You can remove the water reservoir to fill it
or you can fill it directly on the appliance.
Note: If you always use usual commercial
distilled water it is not necessary to descale
the boiler.
CAUTION
Do not use condensation water from the
drier! Do not fill in detergents or other additi-
ons!
A) Remove the water reservoir
Î Pull out the water reservoir using the
handle (A8).
Î Fill the water reservoir up to the "MAX"
marking.
Î Insert the water reservoir and press
downwards.
Operation
Attaching the Accessories
Removing the Accessories
Filling the Water Reservoir
