Kärcher Windsor Armada BRC 40/22 User Manual

14
Operations
Controls
Display
The LED lights in the center are (from left to right):
1. Power
2. Vacuum
3. Brush
4. Solution
5. Eco! Mode.
The switch on the left controls the solution flow. The
switch on the right allows the operator to reverse the
brush motor, effectively moving the machine in an
opposite direction.
The yellow trigger switch on the steering wheel will turn
on the brush and solutions depending on which mode
the control switch is in.
Main Rotary Control Switch
Beginning with the off position and working clockwise,
the modes of operation are:
Brush Only
Encapsulation Mode
Eco! Mode Extraction
Deep Extraction
Vacuum Only
Accessory Tool
Solution Switch
Reverse
Yellow Trigger Switch
1
2
34
5
86409500 Operator’s Manual - Armada BRC 40/22
