Operations
Accessory Tool Connection and Use
NOTE: Use only manufacturer supplied accessory
tools. See Optional Accessories section.
1. Spin the deck 180
° so that the vacuum shoe is at
the front of the machine.
2. To connect solution hose pull back collar and insert
over machine mounted fitting, then release collar to
lock into place. Solution connection can remain
connected at all times.
3. Disconnect vacuum hose from the vacuum shoe
and connect the hand tool to the vacuum hose
connection as shown.
4. Select hand tool position on main rotary control
switch.
5. Press the top of the switch to turn solution on.
6. Press the bottom of the switch to turn solution off if
only the Vacuum will be used for any extended
period of time.
7. Squeeze handle on accessory tool to begin
cleaning.
SOLUTION QUICK
DISCONNECT
VACUUM HOSE
CONNECTION
HAND TOOLHAND TOOL
VACUUM HOSE
HANDTOOL POSITION
86409500 Operator’s Manual - Armada BRC 40/22
