A2xx Technical data
Operating instructions V1.01
43
© KEBA
1 ... Measuring position 2 ... Reference angle
9.2 Environmental conditions
Operating temperature: +5 °C to +40 °C
Charging temperature: +5 °C to +40 °C
Storage temperature: -20°C to +45°C
Relative air humidity: 5% to 95% (non condensing)
9.3 Laser
Laser class: 2 in accordance with IEC 60825-1:2014
Wavelength: 660 nm
Laser output: 7 mW (pulsed)
Laser output calibration uncertainty: ±0.9 mW
Laser beam diameter: 3 mm (at the exit point)
Beam divergence: 35 mrad
Pulse frequency: 167 Hz
IEC 60825-1:2014, Table 10, Condition 3:
200 mm (most restrictive location); 36 µs (im-
pulse duration in orifice plate)
9.4 Power supply unit
Designation: Switching Power Supply
Model: PSAI05R-050QL6
Input voltage: 100 - 240 V AC, 50 - 60 Hz
Input current: max. 0.3 A
