A2xx Operation and handling
Operating instructions V1.01
27
© KEBA
Main menu
(1st level)
Display
(2nd level)
Description
Menu 4/5
Settings
Menu 15/16
Disc
Formatting the internal memory. All data is deleted.
1)
Disc
Format?
Menu 16/16
Reset
Reset all parameters to the default settings
1)
.
Settings
Reset?
Menu 5/5
ErrLog
No more
errors!
Error memory for messages that have occurred. See
Chapter "Errors".
Axxx
v01.03
Switch-off and display of the installed software version
1)
This function is started by pressing and holding the operating button. By
pressing it 2x briefly, the menu item is exited again without triggering the
function.
2)
If the value is too high, the motion of the press beam may no longer be de-
tected; at a value that is too low, faulty triggering is possible. Use in the Ma-
chine operating mode in move down and move up mode
3)
The lower the value, the earlier a motion of the press beam will trigger the
measurement operation. Use in the Machine operating mode in the motion
mode
4)
The lower the value, the earlier a fluctuating angle value will be ranked as
stable. The measurement is ended as soon as a stable angle has been de-
tected and the press beam has moved upward.
5.5 Operating modes
The following operating modes are available:
● Manual (manual operating mode)
● Machine (automatic operating mode)
5.5.1 Manual
In the Manual operating mode, the angle is measured by hand. For an exact
measurement result, it is recommended that the device be held as still as
possible.
At the end of the measurement, the current angle is indicated on the display.
5.5.2 Machine
In the Machine operating mode, the angle at the press brake is measured.
For this purpose, the device must be attached to the upper tool.
