A2xx Operation and handling
Operating instructions V1.01
33
© KEBA
Continuous measurement
To perform a follow-up check on the workpiece, the device can be set into
continuous measurement mode and the workpiece can be remeasured here
while it is still in the machine. In order to start the continuous measurement,
proceed as follows:
1) Press and hold the operating button until appears on the display.
2) Carry out the measurement.
The measurement can be terminated by pressing the operating button 2x
briefly.
5.8 Data recording and personalization
Data recording
The data recording can be activated and deactivated using settings menu
item Log in the Settings menu. This function is deactivated by default.
If data recording is activated, an entry is created in file ANGLES.CSV after ev-
ery measurement. Approx. 30,000 measurements are saved automatically.
After that point, the file is renamed to ANGLES.BAK and data recording is for-
warded to a new ANGLES.CSV file.
The recorded data can be copied to a PC and evaluated there. To do so, a
connection to the internal memory of the device must be established. The
files (ANGLES.CSV and ANGLES.BAK) can then be transmitted to the PC using
a file explorer. The files can be opened and evaluated with Microsoft
®
Excel,
for example.
The serial numbers and, as an option, personalization data are saved in the
first line of the measurement value files. Measurement values are entered in
the other lines. One line corresponds to one measurement value. For the
measurement values, a comma "," is used to separate decimal places.
Column 1 Date of measurement
Column 2 Time of measurement
Column 3 Measured value in decimal degrees
Column 4
Operating mode in which measurement took place (0 ... Manual, 1 ... Ma-
chine)
● The following format was used for the date: dd.MM.yyyy
● The following format was used for the time of measurement: hh:mm:ss
dd Day (2-digit)
MM Month (2-digit)
yyyy Year (4-digit)
hh Hour (2-digit, 24-hour format)
mm Minute (2-digit)
