REMOTE CONTROL
21
Interface Configuration
USB Remote Interface ......................................................... 21
Configure GPIB Interface ................................................... 22
Configure Ethernet Connection ......................................... 23
USB Remote Control Function Check .............................. 25
eb Server Remote Control Function Check .................. 26
Socket Server Function Check ............................................ 26
USB Remote Interface
USB
configuration
PC side
connector
Type A, host
2260B side
connector
Rear panel Type B, slave
Speed
1.1/2.0 (full speed/high speed)
USB Class
CDC (communications device
class)
Panel operation
1. Connect the USB cable to the rear
panel USB B port.
2. Press the Function key to enter the
Normal configuration settings.
Page 9
Set the following USB settings:
F-22 = 2
Set the rear panel USB port to
USB-CDC.
To Next Page
