Kenwood DDX719 User Manual

78 DDX719/DDX7049BT/DDX419/DDX4049BT/DDX319/DDX3049
Connecting Wires to Terminals
C
onnect to vehicle's reverse lamp
harness when using the optional rear
view camera.
(
Parking sensor wire)
C
onnect to the vehicle's parking
brake detection switch harness.
F
or best safety, be sure to connect
the parking sensor.
⁄
L
ight Green
E
xtension cable (Accessory
2
)
A
ntenna Cord
F
M/AM antenna input
A
ccessory
1
F
USE ( 10A )
(
Steering remote control wire)
L
ight blue/Yellow
T
o use the steering wheel remote control feature, you
need to an exclusive remote adapter (not supplied)
matches your car is required.
I
f no connections are made, do not let the cable come out from the tab.
(
Mute control wire)
B
rown
T
o the terminal that is grounded when either the
telephone rings or during conversation. (To connect the
Kenwood navigation system, consult your navigation
manual.)
T
o car light control switch
(
Dimmer control wire)
O
range/White
D
epending on what antenna you are using, connect
either to the control terminal of the motor antenna, or to
the power terminal for the booster amplifier of the film-
type antenna.
(
Antenna control wire)
B
lue
W
hen using the optional power amplifier, connect to its
power control terminal.
(
Power control wire)
B
lue/White
Y
ellow (Battery wire)
R
ed (Ignition wire)
W
hite
+
/ White/black
-
: To front speaker (left)
G
ray
+
/ Gray/black
-
: To front speaker (right)
G
reen
+
/ Green/black
-
: To rear speaker (left)
P
urple
+
/ Purple/black
-
: To rear speaker (right)
(
Reverse sensor wire)
P
urple/White
B
luetooth Microphone
(Accessory
9
) DDX719/
DDX7049BT/DDX419/DDX4049BT
only
I
gnition key switch
A
CC
C
ar fuse box
(
Main fuse)
S
ubwoofer Preout (monaural)
B
lack (Ground wire)
-
(To car chassis)
B
attery
EN_LVT2268-001A_KR.indb 78EN_LVT2268-001A_KR.indb 78 11/11/22 13:5011/11/22 13:50
