English
|
13
Accessory of KDC-MP439/KDC-MP3039/KDC-MP339
General control
Volume control [VOL]
Source select [SRC]
Volume reduce [ATT]
When the button is pressed again, the volume returns
to the previous level.
In Audio control
Audio item select [AUD]
Adjusts the Audio item [VOL]
⁄
•
Refer to <Audio C
ontrol> (page 6) for the operation
method, such as the procedures for Audio control and
others operations.
In Tuner source
Band select [FM]/[AM]
Station select [4]/[¢]
Recall preset stations [1] — [6]
Basic Operations of remote control
In Disc source
Music select [4]/[¢]
Folder/Disc select
[FM]/[AM]
Pause/Play [38]
⁄
About [ ] (KDC-MP439)
This button is used when Bluetooth HANDS FREE
BOX is connected. For more information, refer to the
instruction manual of Bluetooth HANDS FREE BOX.
About [
✱
] (KDC-MP3039/KDC-MP339)
Not used.
About [DIRECT]
Not used.
¤
• Do not set the remote control in hot places such as
on the dashboard.
Loading and Replacing the battery
Use two “AA”/ “R6”-size batteries.
Slide the cover while pressing downwards to remove
it as illustrated.
Insert the batteries with the + and – poles aligned
properly, following the illustration inside the case.
SRC
DIRECT
/OK
ABC DEF
JKLGHI MNO
TUV
QZ
PRS WXY
VOL
AT T
AU D
FM
+
AM
–
D
KDC-MP439:
KDC-MP3039:
1
1
KDC-MP339:
ATT
SRC
/D
0— 9
DIRECT
FM/AM
VOL
AUD
B64-3901-0000MEn.indd13B64-3901-0000MEn.indd13 07.7.107:18:40PM07.7.107:18:40PM
