4
GETTING ACQUAINTED
KEYS AND CONTROLS
FM DUAL BANDER TH-F7
A/ B-band status LEDs
Green : Busy
Red : Transmitting
Orange: Charging
Tuning Control
VOL Control
Display
PTT switch
LAMP Key
Antenna
Speaker/ Mic.
Keypad
Power Switch
MONI Key
M
Multi-scroll
Key
SP/MIC jack
DC IN jack
Battery release
