85
Maintenance
1. Engine coolant reservoir
2. Engine oil filler cap
3. Brake / clutch fluid reservoir
4. Air cleaner
5. Fuse box
6. Negative battery terminal
7. Positive battery terminal
8. Engine oil dipstick
9. Radiator cap
10.Windscreen washer fluid reservoir
11. Automatic transaxle fluid dipstick
OYB076001R/OYB076002R
■■
Kappa 1.4L MPI Engine (Petrol)
❈ The actual engine room in the vehicle may differ from the illustration.
■■
Kappa 1.2L MPI Engine (Petrol)
