27
10. SPECIFICATIONS
Model IG3000
Type Inverter
Rated Voltage 120
Frequency 60 HZ
Maximum Output 3000W, 25A
Rated Output 2800W, 23.3A
DC Output 12V@5.0A
Engine Model KG205
Engine Type 4 Stroke, overhead valve, single cylinder
Displacement 12.0 cu in (196 cc)
Compression Ratio 8.5:1
Engine Speed 3600 rpm with smart throttle off
Cooling System Forced Air
Ignition System Transistorized
Oil Capacity 0.63 qt (0.6L)
Fuel Tank Capacity 3.1 gal (11.6 L)
Rated Load Run Time 6.25 hours
Noise level-no load-full load @ 23’ (7m) 62-67 dB
Spark Plug WR7DC
Length 27.0 in (686 mm)
Width 16.7 in (425 mm)
Height 19.9 in (505 mm)
Weight 132 lbs (60 kg)
Tune Up Specifications
Spark Plug Gap 0.024-0.028 in (0.6-0.7 mm)
Valve Clearance- cold (Intake) 0.0039 ±.0008 in (0.10 ± 0.02 mm)
Valve Clearance- cold (Exhaust) 0.0059 ± .0008 in (0.10 ± 0.02 mm)
