Kobalt K13015F User Manual

14
K13015FOM_Ver.0406
PARTS LIST
COMPRESSOR
ITEM CODE DESCRIPTION QTY
1 9413190040 TANK 1
2 9415089 PUMP OL195S 1
3 9115011 SCREW M6X16 5
4 9038274 FRONT PANEL UL 1
5 9038275 REAR PANEL UL 1
6 9038276 HANDLE 1
7 9038277 HANDLE UPPER GRIP 1
8 9038278 HANDLE LOWER GRIP 1
9 9038279 TRANSPARENT SHELL 1
10 9038280 CORD HOUSING 1
11
9038281 HANDLE KNOB 2
12 9038282 FIXING BLOCK 2
13 9038283 WHEEL 2
14 9038257 FOOT 2
15 9142572 SCREW PARKER 4,2X25 23
16 9415027 CORD 1
17 9415060 SCREW PARKER 2,9X15 2
18 9050392 DRAIN VALVE 1
19 9414765 POWER SWITCH 1
20 9038260 LOCK CABLE 1
21 9063139
PRESSURE SWITCH/
PRESSURE REGULATOR
1
22 9047061 QUICK COUPLER 1
23 9270026 RILSAN TUBE (INCHES) 16
24 9412469 ELBOW CONNECTION 1
25 9049105 SAFETY VALVE 1
26 9415024 DELIVERY PIPE 1
27 9048016 CHECK VALVE 1
28 9415023 BRACKET FOR TANK 1
29 9415025
BRACKET FOR PRESSURE
SWITCH
1
30 9414744 PRESSURE GAUGE 50 1/4 IN. 1
31 9114280 SCREW M8X14 1
32 9053197 CONNECTION 1
33 9038286
KNOB FOR PRESSURE
REGULATOR
1
34 9053583 ELBOW CONNECTION 2
35 9415139 AIR FILTER 1
PUMP
ITEM CODE DESCRIPTION QTY
50 9415090 GROUP MOTOR/CRANKCASE 1
51 A631000 CYLINDER BARREL 1
52 A610101 CONROD/PISTON 1
53 9040019 SEAL RING 1
54 9415053 CONROD COVER 1
55 9011004 SCREW TORX M5X16 1
56 A650300
GASKET CYLINDER-VALVE
PLATE
1
57 9415091 VALVE PLATE 1
58 9415052
GASKET VALVE PLATE-
CYLINDER HEAD
1
59 9415051 HEAD 1
60 9411131 SCREW M6X35 4
61 9122331 NUT M6 4
62 A661202 CRANKSHAFT 1
63 9170091 BEARING 1
64 9411136 BEARING 2
65 9075047 BELT 1
66 9038193 MOTOR FAN 1
67 9101055 SCREW M5X16 LEFT 1
68 9004015 WASHER SHOULDER 1
69 9411137 SEEGER 1
70 9131010 WASHER 1
71 9038190 SEMIPLASTIC COVER LOW 1
72 9038191 SEMIPLASTIC COVER HIGH 1
73 9142591 SCREW PARKER 3.9X13 4
