Kohler 12EFKOZD User Manual

TP-7044 6/23 61
Figure 23 Decision-Maker 3500 Controller Information Menu Structure
Figure 24 Metering Menu
From Controller Power-Up
DIAL CLICK
MAIN MENU
12:00 AM
12/12/12
METERING
GENERATOR INFO
CONTROLLER CONFIG
I/O
ACTIVE EVENTS
Changes after 3 seconds
From Controller Sleep/Idle Operation
Alternates
every
8 seconds
Alternates
every
8 seconds
DIAL TURN
DIAL PUSH at METERING. Go to the Figure 24.
DIAL PUSH
at GENERATOR INFO. Go to the
Figure 25.
DIAL PUSH
at CONTROLLER CONFIG. Go to the
Figure 26
.
DIAL PUSH
at I/O. Go to the Figure 27.
°F
ENGINE STATUS
12:00 AM
12/12/12
METERING
12:00 AM
12/12/12
GENERATOR METERING
ENGINE METERING
BATTERY CHARGER METERING - - >
OVERVIEW
PARALLELING METERING
Note:
Battery Charger Metering menu options appear but do not apply to these models.
GENERATOR METER
12:00 AM
12/12/12
L1-L2 VOLTS: ###V
L2-L3 VOLTS: ###V
L3-L1 VOLTS: ###V
AVG GEN VOLTAGE L-L: ###V
GEN FREQUENCY: ##.#Hz
L1-L0 VOLTS: ###V
L2-L0 VOLTS: ###V
L3-L0 VOLTS: ###V
AVG GEN VOLTAGE L-N: ###V
GEN FREQUENCY: ##.#Hz
L1 CURRENT: ###A
L2 CURRENT: ###A
L3 CURRENT: ###A
AVG CURRENT: ###A
GEN FREQUENCY: ##.#Hz
L1 POWER: ####W
L2 POWER: ####W
L3 POWER: ####W
TOTAL POWER: ####.#kW
GEN % OF RATED kW: ###%
L1 REACTIVE POWER: ####VAR
L2 REACTIVE POWER: ####VAR
L3 REACTIVE POWER: ###VAR
TOTAL REACTIVE POWER: ####VAR
L1 APPARENT POWER: ####VA
L2 APPARENT POWER: ####VA
L3 APPARENT POWER: ####VA
TOTAL APPARENT POWER: ####VA
GEN % OF RATED kVA: ###%
L1 PF: #.##
L2 PF: #.##
L3 PF: #.##
TOTAL PF: #.##
GEN PHASE ROTATION: ###
DIAL PUSH
DIAL TURN
DIAL PUSH
DIAL PUSH
DIAL PUSH
ENGINE METERING
12:00 AM
12/12/12
ENGINE SPEED: ####RPM
ECM BATTERY VOLTAGE: ##.#VDC
GEN BATTERY VOLTAGE: ##.#VDC
GENSET CONTROLLER TEMP:###°F
OIL PRESSURE: ###PSI
OIL TEMPERATURE: ###°F
COOLANT TEMPERATURE: ###°F
COOLANT PRESSURE: ###PSI
FUEL LEVEL: ###%
FUEL PRESSURE: ###PSI
FUEL TEMPERATURE: ###°F
FUEL RATE: ###GAL/h
FUEL USED LAST RUN: ###GAL
CRANKCASE PRESSURE: ###PSI
INTAKE AIR PRESSURE: ###PSI
INTAKE AIR TEMPERATURE: ###°F
BATTERY X METER
12:00 AM
12/12/12
STATUS:
OUTPUT VOLTAGE: ##.#VDC
OUTPUT CURRENT: ##.#A
CHARGER STATE:
CHARGER TEMP: ###°F
REDUCED OUTPUT ACTIVE: YES/NO
TEMP COMPENSATION ACTIVE: YES/NO
SOFTWARE VERSION: ###########
PARALLEL METERING
12:00 AM
12/12/12
CONNECTED TO BUS: TRUE/FALSE
AVG BUS VOLTAGE L-L: ###.#V
AVG GEN VOLTAGE L-L: ###.#V
BUS FREQUENCY: ##.##Hz
GEN FREQUENCY: ##.##Hz
BUS TOTAL POWER: #####.#kW
BUS % OF RATED kW: ###%
BUS % OF RATED kVAR: ###%
COOLANT
TEMPERATURE
OIL PRESSURE
GEN BATTERY
VOLTAGE
###°F
###PSI
##.#Hz
GENERATOR STATUS
12:00 AM
12/12/12
SYSTEM STATUS
12:00 AM
12/12/12
AVGGEN
VOLTAGE L-L
AVG CURRENT
GEN
FREQUENCY
###V
###A
##.#Hz
FUEL
PRESSURE
TOTAL POWER
TOTAL RUN
TIME
###PSI
####Kw
####HRS
Alternates every
8 seconds
Alternates every
8 seconds
DIAL PUSH
