TP-6198 3/15 13Section 1 Specifications
Section 1 Specifications
1.1 Introduction
The spec sheets for each generator set p rovide specific
generator and engine information.
See the generator set specification sheets for generator
ratings and other generator set data not supplied in this
manual. Consult the generator set nameplate for
specific generator set ratings.
Consult the engine operation manual and engine
service manual for engine specifications.
1.2 Controller Specifications
The generator set is equipped with the ADC 2100. For a
specific description of the controller, see Section 2,
Operation, in the operation manual.
Environmental Specification
Operating temperature
-- 2 0 _ to 70_C
(--4_ to 158_F)
Storage temperature
-- 6 0 _ to 70_C
(--76_ to 158_F)
Humidity 0%--95% condensing
Power requirements:
Voltage 12 VDC
Current
250 mA @ 12 VDC
1.3 Engine Specifications
Engine Specification 15 kW 30 kW
Manufacturer GM
Model 1.6L OHC
Cycle 4
Number of cylinders 4
Compression ratio 9.4:1
Displacement, L (cu. in.) 1.6 (98)
Rated power, propane fuel,
kWm (BHP)
19.0 (25.5) 37.2 (50)
Rpm, 60 Hz 1800 3600
Rpm, 50 Hz NA 3000
Bore x stroke, mm (in.) 79 x 81.5 (3.11 x 3.21)
Valve (exhaust) material High alloy steel
Cylinder head material Aluminum
Piston rings 2 compression/1 oil control
Piston material
High silicon content
aluminum
Crankshaft material Cast iron
Main bearings: quantity,
type
5, replaceable inserts
Governor Electronic
Lubrication system Full pressure
Oil capacity (w/filter), L (qt.) 3.5 (3.7)
Oil capacity with makeup
kit, L (qt.)
5.4 (5.7)
Oil pressure, kPa (psi) 150 (22)
Fuel system LP gas or natural gas
LP/natural gas minimum
supply pressure,
oz./in.
2
(in. H
2
O)
4--6 (7.11)
Battery voltage 12 VDC
Battery ground Negative
Spark plug gap, mm (in.) 0.8--0.9 (0.031--0.035)
Ignition system Distributorless electronic
Starter motor Solenoid-actuated pinion
Cooling system Water-cooled
Valve material
Intake
Exhaust
Chrome/silicone steel
Stellite F
