TP-6198 3/1544 Section 4 Controller
4.9.2 Controller Configuration
The controller configuration for each generator model is
set at the factory and should not normally require
changes. The controller ’s configuration mode allows
adjustment of the system parameters listed in this
section. Use the instructions in this section to check the
configuration after installation and change them to
match the settings shown in Figure 4-15, if necessary.
Parameter Setting Definition
Unit’s system voltage and frequency
Uu01 Single phase, 60 Hz, 120/240 VAC
Uu04 Three phase, 60 Hz, 138/277 or 240/480 VAC
Unit configuration Uc01 * Standby
Engine type
Ec03 * 15RYG/RES
Ec06 * 30RYG/RES
Engine data input types
SeeFigure4-16.
Ed01 * 15/30RYG/RES
Ed02 15/30RYG/RES with Remote Digital Gauge
Battery voltage
Bt12 * Battery voltage 12 VDC
Bt24 Battery voltage 24 VDC
Communications
Cn00 * No CAN communications
Cn01 J1939 (use for Remote Digital Gauge)
* Factory settings.
Figure 4-15 Configuration Parameters
Parameter Low Coolant Level Sensor Pressure Sensor Temperature Sensor Magnetic Pickup
Ed00 Digital Switch Digital Switch Digital Switch No
Ed01 Digital Switch Digital Switch Analog Sender No
Ed02 Digital Switch Analog Sender Digital Switch No
Ed03 Digital Switch Analog Sender Analog Sender No
Ed04 Digital Switch Digital Switch Digital Switch Yes
Ed05 * Digital Switch Digital Switch Analog Sender Yes
Ed06 Digital Switch Analog Sender Digital Switch Yes
Ed07 Digital Switch Analog Sender Analog Sender Yes
Ed08 Analog Sender Digital Switch Digital Switch No
Ed09 Analog Sender Digital Switch Analog Sender No
Ed10 Analog Sender Analog Sender Digital Switch No
Ed11 Analog Sender Analog Sender Analog Sender No
Ed12 Analog Sender Digital Switch Digital Switch Yes
Ed13 Analog Sender Digital Switch Analog Sender Yes
Ed14 Analog Sender Analog Sender Digital Switch Yes
Ed15 Analog Sender Analog Sender Analog Sender Yes
* Factory setting for replacement controllers. See Figure 4-15 for the default settings for certain models. The installation of optional sender
kits (available for some models) may require a different Ed setting.
Figure 4-16 Engine Data Input Types, Parameter Ed
