TP-5986 4/032 Section 1 Specifications
1.5 Generator
Component Specification Value
Rotor field voltage/current readings at rated voltage (hot)
No load (63 Hz) (volts/amps) 13/3.82
Full load (60 Hz) (volts/amps) 47/13.82
Cold main field (rotor) resistance (ohms) 3.4
Stator output voltages with separately excited generator,
using 12-volt battery (60 Hz only)
1--2, 3--4, 33--44 (VAC) 145
55--66 (VAC) 190
B1-B2 (VAC) 14
Cold stator resistance
1--2, 3--4, 33--44 (ohms) 0.16
55--66 (ohms) 1.70
B1-B2 (ohms) 0.05
1.6 Torque
Component Torque Nm (in. lbs.)
Rotor bolt 23.1 (204)
Generator overbolts 13.6 (120)
Mounting plate to end bracket
bolts
6.8 (60)
Lift eye bolts 19.0 (168)
Generator adapter to engine
bolts
14.9 (132)
Engine oil drain boss (inside
generator adapter)
47.5 (420)
Generator adapter to exhaust
manifold
13.6 (120)
High exhaust temp. switch 13.6 (120)
Spark plugs 12--17 (106--150)
Bolts that hold the coverplate
over the impeller
3.4 (30)
