Kohler Courage XT-6 Service Manual

8.1
Section 8
Disassembly
8
Section 8
Disassembly
WARNING: Accidental Starts!
Disabling engine. Accidental starting can cause severe injury or death. Before working on the engine or equipment,
disable the engine by disconnecting the spark plug lead.
The following sequence is a step-by-step guide for
complete engine disassembly. This procedure may
vary depending on the options included.
Thoroughly clean all engine parts during the
disassembly process. This allows for more accurate
inspection and gauging of the engine for wear or
damage. Use a commercial cleaner to remove grease,
oil, and grime from engine parts. When such a cleaner
is used, follow the manufacturer’s instructions and
safety precautions carefully.
Remove all traces of cleaners before the engine is
reassembled and placed into operation. Even small
amounts of these cleaners can quickly break down the
lubricating properties of engine oil.
Basic Disassembly Sequence
1. Disconnect spark plug lead.
2. Ensure fuel tank is empty.
3. Remove fuel cap.
4. Drain oil from crankcase.
5. Remove engine cover insert.
6. Remove engine cover.
7. Remove recoil.
8. Remove blower housing.
şǯȱ ȱĝȱǯ
ŗŖǯȱ ȱĝȱȱȱĚȱǯ
ŗŗǯȱ ȱȱȱȱȱęǻǼǯ
12. Disconnect breather hose.
13. Remove air cleaner base.
14. Disconnect primer hose.
15. Disconnect fuel line.
16. Remove carburetor.
17. Disconnect carburetor linkage.
18. Remove carburetor gaskets.
19. Remove governor spring.
20. Remove speed control bracket.
22. Remove governor lever.
23. Remove fuel tank.
24. Disconnect kill lead from ignition module.
25. Remove ignition module.
ŘŜǯȱ ȱĚ¢ȱȱǯ
Řŝǯȱ ȱĚ¢ȱȱȱȱǯ
28. Remove fan.
Řşǯȱ ȱĚ¢ǯ
30. Remove breather cover.
31. Remove breather spring, disc and screen.
32. Remove spark plug.
řřǯȱ ȱĚ¢ȱȱ¢ǯ
34. Remove valve cover and gasket.
35. Remove jam nuts and rocker arm pivots.
36. Remove rocker arms
37. Remove push rods.
38. Remove guide plate.
39. Remove rocker studs.
40. Remove cylinder head.
41. Remove valves.
42. Remove dipstick tube.
43. Remove oil pan and gasket.
ŚŚǯȱ ȱĞǯ
45. Remove governor gear and retainer.
ŚŜǯȱ ȱȱȱȱĞǯ
47. Remove tappets.
48. Remove connecting rod cap.
49. Remove piston with connecting rod.
śŖǯȱ ȱĞǯ
