Komatsu D155A-6 User Manual

.
MAINTENANCE
SERVICE PROCEDURE
Angledozer
(1)
(2)
Lift cylinder support yoke (4 places)
Lift cylinder support shaft (2 places)
(3) Tilt brace screw (2 places)
Ripper
(1) Tilt cylinder bottom pin (1 place)
(2) Lift cylinder bottom pin (1 place)
(3) Tilt cylinder rod end pin (1 place)
(4) Lift cylinder rod end pin (1 place)
(5) Arm pin (front) (2 places)
(6) Arm pin (rear) (2 places)
4 - 57
