2. Removal of exterior parts under floor
1) Removal of right lower cover (washer fluid tank)
(1) Disconnect the washer fluid tank harness and remove one harness clamp
.
(2) Remove one washer fluid hose clamp.
(3) Remove the cover mounting bolts.
(4) Remove the cover and washer fluid tank
.
Harness clamp
01024-81020 x1
04434-51410 x1
01024-81020 x1
04434-51410 x1
Q't
y
Name Q't
y
Others
Name
Precautions
1 × 2 ×
5 ×
NO.0020
3 × 4 × 6 ×
Facilities to be used
Preparation - Removal of exterior parts under floo
r
(
1/3
)
Assembly procedure
Tools to be used
(1) Remove the connector from the motor on the washer fluid tank and remove
one harness clam
p
.
Right side under
the floor
Front of machine
View from underside of machine
(2) Remove the windshield washer hose clamp on the reverse of the cover at the rear of the
machine
.
CN-L10
(REAR WASHER MOTOR)
CN-L09
(FRONT LOWER WASHER MOTOR)
CN-L08
(FRONT UPPER WASHER MOTOR)
12
