4. Preparation on cab side
1) Removal of cover and duct at rear in cab
01024-D0612x
01024-D0816
01024-81016
Q't
Name Q't
Others
Tools to be used
Name
3 ×
4 ×
5 ×
6 ×
Facilities to be used
Preparation - Removal of parts on cab sideNO.0040
Assembly procedure
(1) Remove the cover at the inside rear of the cab an
the cushion material on the reverse.
(2) Remove the fresh air intake duct of the ai
conditioner.
Precautions
1 ×
2 ×
(1) Remove the four bolts to remove the cover and the cushion on the reverse.
(2) Remove the two bolts to remove the fresh air intake duct of the air conditioner.
