OPERATION
MACHINE OPERATIONS AND CONTROLS
Loading Work
In
places
where
the
swing
angle
is
narrow,
work
efficiency
can
be
enhanced
by
locating
the
dump
truck
in
a
place
easily
visible
to
the
operator.
Loading
is
easier
and
capacity
greater
if
you
begin
from
the
front
of
the
dump
truck
body
than
if
loading
is
done
from
the
side.
