FOREWORD
INTRODUCTION
INTRODUCTION
USE OF MACHINE
This Komatsu machine is designed to be used mainly for the following work:
Digging work
Leveling work
Ditching work
Loading work
Demolition work
See the section "RECOMMENDED APPLICATIONS (PAGE 3-167)" for further details.
DIRECTIONS OF MACHINE
(A)
(B)
(C)
(D)
Front
Rear
Left
Right
(E)
(F)
Operator's seat
Sprocket
In this manual, the terms front, rear, left, and right refer to the travel direction as seen from the operator's seat when
the operator's seat is facing the front and the sprocket is at the rear of the machine.
VISIBILITY FROM OPERATOR'S SEAT
This machine complies with the visibility standard (ISO 5006).
This machine maintains a close visibility of a height of 1.5 m at a point 1 m away from the outside surface of the
machine, and a visibility for a circumference of 12 m.
1 - 4
