MAINTENANCE
MAINTENANCE PROCEDURE
Shroud
1.
Place
a
bar
on
the
head
of
pin
(1),
hit
the
bar
with
a
hammer
to
knock
out
the
pin,
then
remove
tooth
(2).
REMARK
If
it
cannot
be
removed
by
this
method,
for
safety
reasons,
always
contact
your
Komatsu
distributor
to
have
the
replacement
carried
out.
2. Clean
the
mounting
face.
Fit
a
new
shroud
(2)
in
the
adapter,
push
in
pin
(1)
partially
by
hand,
then
lock
it
with
a
hammer
to
install
the
tooth
to
the
bucket.
4 - 36
298
300
