INTRODUCTION OF ATTACHMENTS AND EXTENDING MACHINE SERVICE LIFE OPTIONS, ATTACHMENTS
330 PW160-7H VEAM390100
Grabbing a object using buckets on only one side
Closing the sub-bucket with the boom and arm fully extended.
Impact operation with no load.
SCRAP GRAPPLE
MAIN FIELDS OF APPLICATION
● Disposal of rock or debris
This attachment is mounted to the arm end and used to grasp
rock, debris etc. by opening and closing the claws (3 to 5) corre-
sponding to the extension and retraction of the hydraulic cylinder.
MISTAKEN METHODS OF USE
To ensure that the machine has a long life, and to ensure that
operations are carried out in safety, do not operate the machine in
any of the following ways.
● Do not operate the cylinder to the end of its stroke.
Always leave approx. 5 cm to spare.
AM092310A
AM092340A
