Connecting the TP-573 and TP-574
8
5 Connecting the TP-573 and TP-574
You can use the TP-573 HDMI/RS-232/IR Line Transmitter with the TP-574
HDMI/RS-232/IR Line Receiver to configure an HDMI transmitter/receiver
system.
To connect the TP-573 to the TP-574, as illustrated in the example in
Figure 3
, do the following:
On the TP-573 connect:
1. An HDMI source (for example, a DVD player) to the HDMI IN connector.
2. An IR sensor or emitter to the IR 3.5mm mini jack connector.
3. An RS-232 source (for example, a computer) to the RS-232 9-pin D-sub
connector
1
.
4. A CAT 5
2
or CAT 6
2
cable to the LINE OUT RJ-45 twisted pair connector.
On the TP-574 connect:
1. The HDMI OUT connector to an HDMI acceptor (for example, an LCD
display with speakers).
2. An IR emitter or sensor to the IR 3.5mm mini jack connector.
3. The RS-232 9-pin D-sub connector to an RS-232 acceptor (for example, an
RS-232 controllable device)
1
.
4. The CAT 5
2
or CAT 6
2
cable from the TP-573 to the LINE IN RJ-45
twisted pair connector.
5. The 12V DC power supply to the TP-573 (not shown in Figure 3
).
1 See section 5.1
2 Using the Kramer BC-DGKat524 and BC-DGKat623 cables, respectively
