11 SERVICE WORK ON THE CHASSIS 178
100752-01
– Check the fluid level.
The fluid level must be between the MIN and MAX markings.
» If the coolant level does not meet specifications:
– Correct the fluid level of the hydraulic clutch. ( p. 178)
11.18 Correcting fluid level of hydraulic clutch
Info
The fluid level rises with increasing wear of the clutch lining disc.
Do not use brake fluid.
– Move the clutch fluid reservoir mounted on the handlebar to a horizontal position.
100753-01
– Remove screw cap with membrane.
– Correct the fuel level.
Guideline
The fluid level must be between the MIN and MAX markings.
Hydraulic fluid (15) ( p. 268)
– Refit the screw cap with the membrane.
