23 TECHNICAL DATA 258
Front 320 mm (12.6 in)
Rear 220 mm (8.66 in)
Brake discs - wear limit
Front 4.5 mm (0.177 in)
Brake disc - wear limit
Rear 4.5 mm (0.177 in)
Tire air pressure, solo
Front 2.5 bar (36 psi)
Rear 2.5 bar (36 psi)
Tire air pressure with passenger / full payload
Front 2.5 bar (36 psi)
Rear 2.9 bar (42 psi)
Secondary drive 17:38
Chain 5/8 x 5/16” X‑ring
Steering head angle 66.7°
Wheelbase 1,425 mm (56.1 in)
Seat height, unloaded
Lower frame rear position 805 mm (31.69 in)
Upper frame rear position 825 mm (32.48 in)
Ground clearance, unloaded 110 mm (4.33 in)
Weight without fuel approx. 186 kg (410 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 240 kg (529 lb.)
Maximum permissible total weight 380 kg (838 lb.)
