SERVICE WORK ON THE CHASSIS 12
127
Finishing work
– Remove the rear of the motorcycle from the lifting gear.
( p. 113)
12.14 Checking the chain, rear sprocket, and engine sprocket
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 113)
100132-10
Main work
– Check the rear sprocket and engine sprocket for wear.
» If the rear sprocket and engine sprocket are worn:
– Change the drivetrain kit.
Info
The engine sprocket, rear sprocket, and chain
should always be replaced together.
