KTM 125 DUKE 2021 User Manual

WHEELS, TIRES 14
149
14.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 113)
– Lift the motorcycle with the front lifting gear. ( p. 114)
F00754-10
Main work
–
Remove screws
1
with washers and push the fender slightly
to the side.
–
Remove screw
2
and pull wheel speed sensor
3
out of the
hole.
–
Loosen screw
4
by several rotations.
–
Loosen screws
5
.
–
Press on screw
4
to push the wheel spindle out of the axle
clamp.
–
Remove screw
4
.
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the
brake disc is not damaged.
– Hold the front wheel and remove the wheel spindle. Take the
front wheel out of the fork.

KTM 125 DUKE 2021 Specifications

General

Displacement	124.7 cc
Bore x Stroke	58 mm x 47.2 mm
Compression Ratio	12.5:1
Transmission	6-speed
Rear Suspension	WP APEX Monoshock
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating caliper, brake disc
Front Tire	110/70 R17
Rear Tire	150/60 R17
Seat Height	830 mm
Dry Weight	139 kg
Frame	Steel Trellis Frame, Powder Coated
Ground Clearance	175 mm
Engine Type	Single Cylinder, 4-Stroke, Liquid Cooled
Torque	12 Nm
Fuel System	Electronic Fuel Injection
Front Suspension	WP APEX 43
Fuel Tank Capacity	13.4 liters
Wheelbase	1, 357 mm
