22 TECHNICAL DATA 130

Screw, top steering stem

(200 XC‑W US, 250 XC‑W US,

300 EXC BR, 300 XC‑W US)

M8 20 Nm (14.8 lbf ft) –

Screw, top steering stem (EXC EU,

EXC Six Days, EXC EU/AU, Six Days)

M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, top triple clamp

(200 XC‑W US, 250 XC‑W US,

300 EXC BR, 300 XC‑W US)

M8 20 Nm (14.8 lbf ft) –

Screw, top triple clamp (EXC EU,

EXC Six Days, EXC EU/AU, Six Days)

M8 17 Nm (12.5 lbf ft) –

Engine bracket screw M10 60 Nm (44.3 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite

243™

Screw, bottom shock absorber M12 80 Nm (59 lbf ft) Loctite

2701™

Screw, top shock absorber M12 80 Nm (59 lbf ft) Loctite

2701™

Nut, seat fixing M12x1 20 Nm (14.8 lbf ft) –

Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –

Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft) –

Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) –

Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –

Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft) Loctite

243™
