13 BRAKE SYSTEM 89
100407-10
–
Check that leaf spring
in the brake caliper and sliding plate
in the brake
caliper support are seated correctly.
M00115-01
– Insert the new brake linings, insert the pin, and mount the cotter pins.
Info
Always change the brake linings in pairs.
– Operate the foot brake lever several times until the brake linings are lying against
the brake disc and there is a pressure point.
400233-10
–
Correct the brake fluid level to marking
.
Brake fluid DOT 4 / DOT 5.1 ( p. 141)
–
Mount screw cap
with membrane
and the O-ring.
Info
Wash off overflowed or spilled brake fluid immediately with water.
