4 TECHNICAL DATA 13

4.1 chassis tightening torques

Remaining screws, chassis EJOT PT

K50x12 1 Nm (0.7 lbf ft) –

Remaining screws, chassis EJOT PT

K50x14 1 Nm (0.7 lbf ft) –

Remaining screws, chassis EJOT PT

K50x16 2 Nm (1.5 lbf ft) –

Remaining screws, chassis EJOT PT

K50x18 2 Nm (1.5 lbf ft) –

Screw, fuel tank cover, quick connect

nipple

EJOT PT

K60 2 Nm (1.5 lbf ft) –

Screw, tail light EJOT PT

K50x14 2.5 Nm (1.84 lbf ft) –

Screw, combination switch, left M4 2.5 Nm (1.84 lbf ft) –

Screw, side stand switch M4 2 Nm (1.5 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, cable channel M5 5 Nm (3.7 lbf ft) –

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –

Screw, combination switch, right M5 3.5 Nm (2.58 lbf ft) –

Screw, cover part M5x12 3.5 Nm (2.58 lbf ft) –

Screw, filler cap M5 3 Nm (2.2 lbf ft) –

Screw, fuel level indicator M5 3 Nm (2.2 lbf ft) –

Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –

Ground fitting on frame M6 10 Nm (7.4 lbf ft) –

Nut, ABS unit attachment M6 5 Nm (3.7 lbf ft) –

Nut, cable on starter motor M6 4 Nm (3 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, battery terminal M6 4.5 Nm (3.32 lbf ft) –

Screw, clutch assembly M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, connecting piece, rear brake

line

M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, cooler retaining bracket M6 7 Nm (5.2 lbf ft) –

Screw, exhaust clamp on main silencer M6 8 Nm (5.9 lbf ft) –

Screw, exhaust clamp on manifold M6 8 Nm (5.9 lbf ft) –

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, fuel pump M6 6 Nm (4.4 lbf ft) –

Screw, headlight mask, rear wall M6 5 Nm (3.7 lbf ft) –

Screw, license plate holder on lower

rear panel

M6 12 Nm (8.9 lbf ft) –

Screw, radiator hose clamp M6 3 Nm (2.2 lbf ft) –

Screw, sensor box M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, shift lever stub M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, shift rod M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, shift shaft deflector on shift

shaft

M6 18 Nm (13.3 lbf ft) Loctite

243™

Screw, side stand stub M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, steering damper, holder, on

frame

M6 8 Nm (5.9 lbf ft) Loctite

243™

Screw, step plate for foot brake lever M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, wheel speed sensor, front M6 4 Nm (3 lbf ft) –

Screw, wheel speed sensor, rear M6 4 Nm (3 lbf ft) –

Nut, manifold on cylinder head M8 Tightening sequence:

Tighten the nuts evenly. Do

not warp the metal plate.

25 Nm (18.4 lbf ft)

–
