4 TECHNICAL SPECIFICATIONS

4.1 chassis tightening torques

Remaining screws, chassis EJOT PT

K50x12 1.2 Nm (0.89 lbf ft)

Remaining screws, chassis EJOT PT

K50x14 1.5 Nm (1.11 lbf ft)

Remaining screws, chassis EJOT PT

K50x16 2.2 Nm (1.62 lbf ft)

Remaining screws, chassis EJOT PT

K50x18 2.2 Nm (1.62 lbf ft)

Remaining screws, chassis EJOT PT

K45x12 1.2 Nm (0.89 lbf ft)

Screw, air filter box cover EJOT PT

K60x30 2.5 Nm (1.84 lbf ft)

Screw, clutch lever 5 Nm (3.7 lbf ft)

Screw, hand brake lever 5 Nm (3.7 lbf ft)

Screw, tail light (SUPER DUKE R) EJOT PT

K50x14 1.5 Nm (1.11 lbf ft)

Screw, fixed grip, left M4 3 Nm (2.2 lbf ft)

Screw, side stand sensor M4 2 Nm (1.5 lbf ft)

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)

Remaining screws, chassis M5 5 Nm (3.7 lbf ft)

screw, absorbing element, combi-

nation instrument

M5 2 Nm (1.5 lbf ft)

Loctite

243™

Screw, cable channel M5 5 Nm (3.7 lbf ft)

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft)

Screw, combination instrument M5 1 Nm (0.7 lbf ft)

Screw, combination switch, left M5 5 Nm (3.7 lbf ft)

Screw, combination switch, right M5 5 Nm (3.7 lbf ft)

Screw, Denso throttle grip M5 3.5 Nm (2.58 lbf ft)

Screw, exhaust valve cover fasten-

ing

EJOT SF

M5 4 Nm (3 lbf ft)

Screw, front turn signal bracket M5 3.5 Nm (2.58 lbf ft)

Screw, fuel level sensor M5 3 Nm (2.2 lbf ft)

Screw, fuel tank filler cap M5 3 Nm (2.2 lbf ft)

Screw, rear turn signal bracket M5 3.5 Nm (2.58 lbf ft)

Screw, trim M5 3.5 Nm (2.58 lbf ft)

Cable disk nut, exhaust valve con-

trol unit

M6 14 Nm (10.3 lbf ft)

Ground fitting on frame M6 10 Nm (7.4 lbf ft)

Nut, cable on starter motor M6 4 Nm (3 lbf ft)

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)

Remaining screws, chassis M6 10 Nm (7.4 lbf ft)

Screw, 6-D sensor cover M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, ABS module fastening M6 8 Nm (5.9 lbf ft)

Screw, ball joint of push rod on

brake cylinder (SUPER DUKE R)

M6 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, battery terminal M6 4.5 Nm (3.32 lbf ft)

Screw, brake cylinder

(SUPER DUKE R)

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, clutch assembly M6 5 Nm (3.7 lbf ft)

Loctite

243™
