6 CONTROLS 31

6.18 Passenger footrests

L02273-01

The passenger footrests can be folded in and out.

Possible states

• Passenger footrests folded up – For operation without a passenger.

• Passenger footrests folded down – For operation with a passenger.

6.19 Shift lever

401950-10

Shift lever



is mounted on the left side of the engine.
