4 TECHNICAL DATA 19

4.1 Chassis tightening torques

Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft) –

Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, battery terminal

(All 200/250/300 models)

M5 2.5 Nm (1.84 lbf ft) –

Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –

Nut, cable on starter motor

(All 200/250/300 models)

M6 4 Nm (3 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, throttle grip M6 5 Nm (3.7 lbf ft) –

Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701™

Nut, rim lock M8 12 Nm (8.9 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp (XC-W,

300 EXC BR)

M8 15 Nm (11.1 lbf ft) –

Screw, bottom triple clamp (Six Days,

EXC EU/AU)

M8 15 Nm (11.1 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, engine brace M8 33 Nm (24.3 lbf ft) Loctite

2701™

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, side stand attachment M8 35 Nm (25.8 lbf ft) Loctite

2701™

Screw, subframe M8 35 Nm (25.8 lbf ft) Loctite

2701™

Screw, top steering stem (XC-W,

300 EXC BR)

M8 20 Nm (14.8 lbf ft) –

Screw, top steering stem (Six Days,

EXC EU/AU)

M8 17 Nm (12.5 lbf ft) Loctite

243™

Screw, top triple clamp (XC-W,

300 EXC BR)

M8 20 Nm (14.8 lbf ft) –

Screw, top triple clamp (Six Days,

EXC EU/AU)

M8 17 Nm (12.5 lbf ft) –

Engine bracket screw M10 60 Nm (44.3 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft) Loctite

243™

Screw, bottom shock absorber M12 80 Nm (59 lbf ft) Loctite

2701™

Screw, top shock absorber M12 80 Nm (59 lbf ft) Loctite

2701™

Nut, seat fixing M12x1 20 Nm (14.8 lbf ft) –

Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –

Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft) –

Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) –

Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –

Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft) Loctite

243™
