KTM 250 SX 2003 User Manual

Workshop manual
Product
Exploded View
Disassembly & Assembling
1
5018 PDS 2003
Shock absorber 5018 PDS 2003 05/2002
Shock absorber
5018 PDS 2003
Introduction 2
Exploded view 3
Disassembly shock absorber 4
Disassembly tube side 13
Disassembly MCC 33
Assembling MCC 39
Assembling Tube side 44
Disassembly piston-rod side 53
Diassembly adaptor DU-bush 63
Assembling adaptor DU-bush 67
Assembling piston-rod side 70
Assembling shock absorber 81
Bleeding 87
On pressure with nitrogen 92
Mounting spring 95
Adjustment 98

KTM 250 SX 2003 Specifications

General

Engine Type	Single-cylinder, 2-stroke
Displacement	249 cc
Bore x Stroke	66.4 mm x 72 mm
Cooling System	Liquid cooled
Transmission	5-speed
Front Suspension	WP USD 48 mm
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Fuel System	Carburetor
Starter	Kickstarter
Final Drive	Chain
Seat Height	925 mm
Fuel Capacity	7.5 l
Rear Suspension	WP PDS shock absorber
