Exploded View
Disassembly & Assembling
Workshop manual
4860 MXMA
36
Frontfork 4860 MXMA 2003 05/2002
Clamp the tube with plug in the
clamping block (T508S and T509) and
assemble the piston-rod “cpl.” into the
tube.
Guide the piston ring!!!
12_177
Before assembling wet the thread of
the screw sleeve with T131.
Screw the screw sleeve into the tube.
12_178
Tighten the screw sleeve.
12_179
