TECHNICAL DATA 22
155
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, retaining bracket of exhaust
control
M5 7 Nm (5.2 lbf ft)
Loctite
®
2701™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Cap nut, water pump impeller M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, alternator cover M6 8 Nm (5.9 lbf ft)
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft)
Screw, control flap, exhaust con-
trol
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, engine case M6 10 Nm (7.4 lbf ft)
Screw, exhaust flange M6 8 Nm (5.9 lbf ft)
Screw, gear oil level check M6 10 Nm (7.4 lbf ft)
Screw, intake flange/reed valve
housing
M6 6 Nm (4.4 lbf ft)
Screw, intermediate clutch cover M6 10 Nm (7.4 lbf ft)
Screw, intermediate kick starter
gear
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, kick starter stop plate M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, outer clutch cover M6 8 Nm (5.9 lbf ft)
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, starter motor bearing bush M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, starter motor protection cap M6 8 Nm (5.9 lbf ft)
Screw, vacuum connections M6 8 Nm (5.9 lbf ft)
Loctite
®
2701™
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Screw, balancer shaft M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, cylinder head M8 27 Nm (19.9 lbf ft)
Screw, kick starter M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Nut, cylinder base M10 35 Nm (25.8 lbf ft)
Screw, drive chain engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Stud, cylinder base M10 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, cylinder head temperature
sensor
M10x1.25 12 Nm (8.9 lbf ft)
Nut, rotor M12x1 60 Nm (44.3 lbf ft)
Gear oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Spark plug M14x1.25 25 Nm (18.4 lbf ft)
