21 TECHNICAL DATA 106
21.5 Electrical system
Battery (All SX‑F standard models) C22S Lithium-ion battery
Battery voltage: 12 V
Nominal capacity: 2.2 Ah
maintenance-free
Battery (XC‑F US, SX‑F Factory Edition) HJTZ5S-FP Lithium-ion battery
Battery voltage: 12 V
Nominal capacity: 2.0 Ah
maintenance-free
Fuse 58011109110 10 A
Malfunction indicator lamp LED
Remaining indicator lamps (XC‑F US) W2.3W/socket W2x4.6d 12 V
2.3 W
21.6 Tires
Validity Front tires Rear tires
(SX‑F EU) 80/100 - 21 51M TT
Dunlop GEOMAX MX3S
110/90 - 19 62M TT
Dunlop GEOMAX MX3S
(SX‑F US, SX‑F Factory Edition) 80/100 - 21 51M TT
Dunlop GEOMAX MX3S
120/80 - 19 63M TT
Dunlop GEOMAX MX3S
(XC‑F US) 90/90 - 21 54M TT
Dunlop GEOMAX AT81F
110/100 - 18 64M TT
Dunlop GEOMAX AT81
The tires specified represent one of the possible series production tires. Additional information is available in the Service section
under:
http://www.ktm.com
21.7 Fork
21.7.1 SX‑F EU
Fork part number 34.18.8Q.09
Fork WP Performance Systems Upside down AER 48
Compression damping
Comfort 15 clicks
Standard 12 clicks
Sport 9 clicks
Rebound damping
Comfort 20 clicks
Standard 17 clicks
Sport 14 clicks
Air pressure 10.8 bar (157 psi)
Fork length 950 mm (37.4 in)
Oil capacity external mecha-
nism right
200
+40
−20
ml (6.76
+1.35
−0.68
fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 112)
Oil capacity external mecha-
nism left
200
+40
−20
ml (6.76
+1.35
−0.68
fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 112)
Oil capacity, right cartridge 380 ml (12.85 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 112)
Grease capacity, left cartridge 11 ml (0.37 fl. oz.) Multi-purpose grease (00062010051) ( p. 114)
21.7.2 SX‑F US
Fork part number 34.18.8Q.59
Fork WP Performance Systems Upside down AER 48
Compression damping
Comfort 20 clicks
Standard 17 clicks
