11 SERVICE WORK ON THE CHASSIS 51
V00310-11
–
Pull off the air filter box cover in area
A
sideways and remove it toward
the front.
V00312-10
(XC‑F US)
Condition
The air filter box cover is secured.
–
Remove screw
1
.
V00312-11
–
Pull off the air filter box cover in area
A
sideways and remove it toward
the front.
11.23 Installing the air filter box cover
V00310-12
(All SX‑F standard models, SX‑F Factory Edition)
–
Insert the air filter box cover in area
A
and clip it into area
B
.
V00310-10
Condition
The air filter box cover is secured.
–
Mount and tighten screw
1
.
Guideline
Screw, air filter box cover EJOT PT
®
K60x20-Z
3 Nm
(2.2 lbf ft)
V00312-12
(XC‑F US)
–
Insert the air filter box cover in area
A
and clip it into area
B
.
