22 TECHNICAL DATA 94
Weight without fuel, approx. (SX‑F EU) 106.1 kg (233.9 lb.)
Weight without fuel, approx. (SX‑F USA, SX‑F Factory Edition) 107.3 kg (236.6 lb.)
Weight without fuel, approx. (XC‑F) 109.5 kg (241.4 lb.)
Maximum permissible front axle load 145 kg (320 lb.)
Maximum permissible rear axle load 190 kg (419 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
22.5 Electrical system
Battery (XC‑F) YTX5L-BS Battery voltage: 12 V
Nominal capacity: 4 Ah
Maintenance-free
Battery (All SX‑F models) YTX4L-BS Battery voltage: 12 V
Nominal capacity: 3 Ah
Maintenance-free
Fuse 58011109110 10 A
FI warning lamp LED
22.6 Tires
Validity Front tires Rear tires
(SX‑F EU) 80/100 - 21 M/C 51M TT
Pirelli SCORPION MX Midsoft 32
110/90 - 19 62M TT
Pirelli SCORPION MX Midsoft 32
(SX‑F USA) 80/100 - 21 M/C 51M TT
Dunlop GEOMAX MX 51 FA
110/90 - 19 62M TT
Dunlop GEOMAX MX 51
(SX‑F Factory Edition) 80/100 - 21 M/C 51M TT
Dunlop GEOMAX MX 52 F
110/90 - 19 62M TT
Dunlop GEOMAX MX 52
(XC‑F) 80/100 - 21 M/C 51M TT
Dunlop GEOMAX MX 51 FA
110/100 - 18 64M TT
Dunlop GEOMAX MX 51
Additional information is available in the Service section under:
http://www.ktm.com
22.7 Fork
22.7.1 SX‑F EU
Fork part number 14.18.7N.09
Fork WP Suspension Up Side Down 4860 MXMA CC
Compression damping
Comfort 14 clicks
Standard 12 clicks
Sport 10 clicks
Rebound damping
Comfort 14 clicks
Standard 12 clicks
Sport 10 clicks
Spring length with preload spacer(s) 490 mm (19.29 in)
Spring rate
Weight of rider: 65… 75 kg (143… 165 lb.) 4.8 N/mm (27.4 lb/in)
Weight of rider: 75… 85 kg (165… 187 lb.) 5.0 N/mm (28.6 lb/in)
Weight of rider: 85… 95 kg (187… 209 lb.) 5.2 N/mm (29.7 lb/in)
Gas pressure 1.2 bar (17 psi)
Fork length 940 mm (37.01 in)
Oil capacity per cartridge 195 ml (6.59 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 100)
Oil capacity fork leg without
cartridge
390 ml (13.19 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 100)
