SERVICE WORK ON THE CHASSIS 12

12.48 Installing the engine guard (All EXC-F Six Days, XCF‑W)

H01638-10

– Attach the engine guard on the frame at the rear and swing up

at the front.

–

Mount and tighten screws

Guideline

Remaining screws,

chassis

M6 10 Nm (7.4 lbf ft)
